LD212-35+5MR-HYJ PJ 40′ GOOSENECK TRAILER 25,900 -30,000 GVWR W/ MONTSTER RAMPS LR-G TIRES ELEC/HYD DISC BRAKES & DUAL HYDRAULIC JACKS
Store ID #LD212-35+5MR-HYJ
Price: $24,795.00
- (2) 12,000# Dual Wheel w/ Electric Brakes (Oil Bath)
- ** Can be rated at 30,000 GVWR **
- HYDRAULIC LANDING GEAR
- Hydraulic DISC BRAKES
- 30,000 LB ADJUSTABLE SUSPENSION
- 14 PLY Tire Upgrade
- 1 PIECE ENGINEERED NECK !
- FULL WIDTH MONSTER RAMPS
Print Product Specifications
The LD from PJ Trailers is our super heavy-duty gooseneck trailer. This unit comes equipped with 12,000-lb axles and is perfect for hauling even the heaviest equipment. This unit offers Hydraulic Disc Brakes for maximum stopping. Hydraulic Monster Jacks to make unhooking from your tow vehicle easy. This trailer Can be Rated From 16,000 GVWR up to 30,000 GVWR upon request. This is a great option for Hotshot hauling or Hauling heavy equipment up to 20,000 lbs on the deck.
- 2-5/16″ Ball Adjustable Coupler- Square Crank Type
- Dual Landing Gear (Bolted On)
- Low Profile Bed, Pierced- Beam Frame
- 102″ Overall Width
- (2) Side Bed Steps & Handles
- Lockable Toolbox Between GN Uprights
- 3/8″ Heavy Duty Rub Rail
- Tie Down Pockets Along Sides, 24″ On Center
- 1-1/4″ Pipe Chain Spools Between Tie Down Pockets
- Oil Bath Hubs
- Lippert Brand Axles
- Forward Self Adjusting Brakes
- Torque Tube Standard on 28 (Flat Deck) & Longer
- Heavy Duty 30,000# Adjustable Suspension by Lippert Axle
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Modular Sealed Wiring Harness
- Mega Ramps
- Complete Break-A-Way System w/Charger
- Spare Tire Mount (Top of Neck)
- Radial Tires
- Spare Tire & Wheel – Standard Equipped
- Mudflaps
| AXLE | (2) 12,000# Dual Wheel w/Electric Brakes (Oil Bath) |
|---|---|
| JACK | Dual Hydraulic Landing Gear |
| TIRE | ST235/80 R-16 Load Range G Dual |
| FLOOR | 2″ Treated Pine or Douglas Fir* |
| FRAME | 12″ I Beam, 22# |
| WHEEL | 16″ x 6.75″ |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| LIGHTS | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| COUPLER | 2-5/16″ Ball Adj. Square Crank Type |
| NECK | 1 Piece Engineered Neck |
| G.V.W.R. | 25,900# – 30,000# |
|---|---|
| TOP RAIL | None |
| ELEC. PLUG | 7-Way RV |
| HITCH TYPE | Gooseneck |
| SIDE RAILS | 6″ Channel w/Rub Rail, Tie Down Pockets on 24″ Centers, and Chain Spools |
| SUSPENSION | Heavy Duty 30,000# Adjustable |
| CROSSMEMBERS | 16″ Centers |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| SAFETY CHAINS | 3/8″ Grd. 70 w/Safety Latch Hook (2 each) |
| G.A.W.R. (Ea. Axle) | 12,000# |
