BIG TEX 30′ GOOSENECK TRAILER 15 TON TANDEM DUAL 3XGN-25+5 MEGA RAMPS

Store ID #3XGN-25+5

Price: $18,995.00

  • (2) 15,000# Dual Wheel w/ Electric Brakes (Oil Bath)
  • Low Profile Bed, Pierced- Beam Frame
  • Mega Ramps
  • Dexter Brand Axles
  • Dual Two Speed Landing Gear
  • Radial Tires
  • 12″ I Beam Frame, 22#
  • Tie Down Pockets Along Sides, 24″ On Center
Contact Dealer
Print Product Specifications

The 3XGN from Big Tex Trailers is our super heavy-duty gooseneck trailer. This unit comes equipped with 15,000-lb axles and is perfect for hauling even the heaviest equipment. Enjoy peace of mind when standing up to the rugged conditions with the 3XGN.



  • 2-5/16″ Ball Adjustable Coupler- Square Crank Type
  • Dual Two Speed Landing Gear 50K Capacity (Bolted On)
  • Low Profile Bed, Pierced- Beam Frame
  • 102″ Overall Width
  • (2) Side Bed Steps & Handles
  • Lockable Toolbox Between GN Uprights
  • 3/8″ Heavy Duty Rub Rail
  • Tie Down Pockets Along Sides, 24″ On Center
  • 1-1/4″ Pipe Chain Spools Between Tie Down Pockets
  • Oil Bath Hubs
  • Dexter Brand Axles
  • Forward Self Adjusting Brakes
  • Torque Tube Standard on 28 (Flat Deck) & Longer
  • Heavy Duty 30,000# Adjustable Suspension by Dexter Axle
  • Grommet Mount Sealed Lighting
  • L.E.D. Lighting Package
  • Modular Sealed Wiring Harness
  • Mega Ramps
  • Complete Break-A-Way System w/Charger
  • Spare Tire Mount (Top of Neck)
  • Radial Tires
  • Spare Tire & Wheel – Standard Equipped
  • Mudflaps



AXLE (2) 15,000# Dual Wheel w/Electric Brakes (Oil Bath)
JACK Dual Two Speed Landing Gear
TIRE ST215/75 R-17.5 Load Range H Dual
FLOOR 2″ Treated Pine or Douglas Fir*
FRAME 12″ I Beam, 22#
WHEEL 17.5″ HC x 6.75″, 8×275 MM BC Hub Pilot
FINISH Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.
LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
COUPLER 2-5/16″ Ball Adj. Square Crank Type
NECK 12″ I Beam, 22#
G.V.W.R. 30,000#
TOP RAIL None
ELEC. PLUG 7-Way RV
HITCH TYPE Gooseneck
SIDE RAILS 8″ Channel w/Rub Rail, Tie Down Pockets on 24″ Centers, and Chain Spools
SUSPENSION Heavy Duty 44,000# Adjustable
CROSSMEMBERS 6″ Jr I Beam, 16″ Centers
FINISH (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish.
SAFETY CHAINS 3/8″ Grd. 70 w/Safety Latch Hook (2 each)
G.A.W.R. (Ea. Axle) 15,000#

Additional information

Brand

Big Tex

Width

8.5'

Length

30'

Load Capacity

18,000

GVWR

25,900

Tounge Type

Gooseneck
