BIG TEX 30′ GOOSENECK TRAILER 12 TON 22GN-25+5

Store ID #22GN-25+5

Price: $9,895.00

  • Low Profile Bed, Pierced- Beam Frame
  • 5 Dovetail w/ 5 Double Hinged Spring Assist Flip-Over Ramps
  • Dexter Brand Axles
  • Dual 12,000# Drop Leg Jacks (Bolted on)
  • Radial Tires
  • Oil Bath Hubs
  • Grommet Mount Sealed Lighting
  • Tie Down Pockets Along Sides, 24″ On Center
Contact Dealer
Print Product Specifications

The 22GN from Big Tex is our durable gooseneck trailer equipped with 10K heavy-duty axles with Dexter Adjustable suspension. This unit features a low-profile pierced-beam frame, LED lights, adjustable dual jacks, a chain box and a crank-style adjustable coupler



  • 2-5/16″ Ball Adjustable Coupler- Square Crank Type
  • Dual 12,000# Drop Leg Jacks- (Bolted On) w/ Greasable Handle
  • Low Profile Bed, Pierced- Beam Frame
  • 102″ Overall Width
  • (2) Side Bed Steps & Handles
  • Lockable Toolbox Between GN Uprights
  • 3/8″ Heavy Duty Rub Rail
  • Tie Down Pockets Along Sides, 24″ On Center
  • 1-1/4″ Pipe Chain Spools Between Tie Down Pockets
  • Oil Bath Hubs
  • Dexter Brand Axle
  • Cambered Axles
  • Forward Self Adjusting Brakes
  • Heavy Duty 30,000# Adjustable Suspension by Dexter Axle
  • Torque Tube Standard on 28 (Flat Deck) & Longer
  • Grommet Mount Sealed Lighting
  • L.E.D. Lighting Package
  • Modular Sealed Wiring Harness
  • 5 Dovetail w/ 5 Double Hinged Spring Assisted Flip-Over Ramps
  • Complete Break-A-Way System w/Charger
  • Spare Tire Mount (Top of Neck)
  • Radial Tires
  • Zip Breakaway Cable
  • Spare Tire & Wheel – Standard Equipped
  • Mudflaps



AXLE (2) 10,000# Dual Wheel w/Electric Brakes (Oil Bath)
JACK Dual 12,000# Drop Leg Jacks (Bolted On)
TIRE ST235/80 R-16 Load Range E DUAL
FLOOR 2″ Treated Pine or Douglas Fir*
FRAME 12″ I Beam, 16#
WHEEL 16″ x 6″; Dual Wheel 8 Bolt
FINISH Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.
LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance
COUPLER 2-5/16″ Ball Adj. Square Crank Type
NECK 12″ I Beam, 16#
G.V.W.R. 23,900#
TOP RAIL None
ELEC. PLUG 7-Way RV
HITCH TYPE Gooseneck
SIDE RAILS 6″ Channel w/Rub Rail, Tie Down Pockets on 24″ Centers, and Chain Spools
SUSPENSION Heavy Duty 30,000# Adjustable
CROSSMEMBERS 3″ Channel
FINISH (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish.
SAFETY CHAINS 3/8″ Grd. 70 w/Safety Latch Hook (2 each)
G.A.W.R. (Ea. Axle) 10,000#

Additional information

Brand

Big Tex

Width

8.5'

Length

30'

Load Capacity

17,600

GVWR

23,900

Tounge Type

Gooseneck
